| Item |
Specifications |
Description |
| Model Name |
CHL-818E |
Non-medical application |
| Measure Method |
5-segment, 8-point tactile electrode measure time: about 10 seconds |
Upper left and right limb, lower left and right limb, trunk |
| Measure Current |
50kHz, 0.5mA |
Frequency that tells accurate body composition, safe and close to human body natural current |
| Capacity |
150 kg |
Cannot measure weight if exceed 150kg |
| Personal Information |
Age: 6-85 years old Gender: female/male Height: 100-210cm Unit:0.5cm |
Cannot save measurements if exceed data range |
| Analyzer Databse |
8 user memory, 180 entries for each user. |
Can save 8 users info, 180 entries for each one |
| History Inquiry |
Automatically calculate the D-value between historical and current entries. |
Up to 180 entries for each user |
| Test Result |
Condition judgement:
Too Low/Low/Standard/High/Too High |
Read measurements and comparison analysis on the display |
| Operating |
Avoid wet and serious magnetic noise interference. |
Extreme temperature, humidity and radiation may cause instrument failure. Please operate properly to prolong the service life and ensure accuracy. |
| Dimensions |
L 37cm * W 34cm* H 4cm, net weight: 3.3kg |
Wide main body makes it hard to rollover and safe. Light and portable. |
| Power Supply |
One built-in 3.7V/800mAh rechargeable lithium battery. |
Ask sales staff for power supply option. |
| Charge Voltage |
DC 5V, < 1A,
Please use smart phone power adaptor to charge. |
Please use proper power adaptor |
| Bluetooth Version |
Bluetooth 4.0 (BLE) |
Use smart phone or tablet which support BT4.0 BLE. Android 4.2+( IOS system willbe available). |
| Standby Power Consumption |
0.3mW, Duration: 1 week |
Duration may be longer if fully charged. |
